Power Electronics SD750 Series User Manual

SD750
POWER ELECTRONICS
22
DIMENSIONS
Dimensions of Frames 3, 4 and 5
TALLA
TENSIÓN DE ENTRADA
EQUIPOS
3
380 – 480VAC (-10% a +10%)
SD750095 5B06DEF, SD750110 5B06DEF, SD750145 5B06DEF, SD750180 5B06DEF
4
380VAC – 480VAC (-10% a +10%)
SD750200 5B06DEF, SD750260 5B06DEF
5
380VAC – 480VAC (-10% a +10%)
SD750320 5B06DEF, SD750400 5B06DEF
TALLA
DIMENSIONES (mm)
PESO
(kg)
H1
H2
W1
W2
W3
W4
D1
D2
D3
D4
Y1
Y2
Y3
Y4
3
854
839
301
200
140
-
358
-
-
-
827
15
-
-
67,5
4
1249
1208
320
284
-
-
466
148
70
1145
682
75
313
94
5
1716
1667
431
298
67
396
529
100
194
467
1370
1220
75
237
200
Dimensions of Frame 3 Dimensions of Frame 4
Dimensions of Frame 5
