TECHNICAL CHARACTERISTICS
6 programmable to be active high (PNP) or low (NPN), Isolated power supply
3 programmable changeover relays (250Vac, 8A or 30Vdc, 8A)
3 programmable inputs: 0 – 20mA, 4 – 20mA, 0 – 10Vdc (optically isolated)
2 isolated programmable outputs: 0 – 20mA, 4 – 20mA, 0 – 10Vdc
ENCODER INPUTS (Optional)
Two differential encoder inputs. Voltages inputs from 5 to 24Vdc
+24Vdc user power supply, (Max. 180 mA) regulated and short-circuit protected
+10Vdc user power supply, (Max. 2 potentiometers R= 1 k) regulated and short-circuit
protected
I/O EXTENSION BOARD
(Optional)
5 Digital Inputs: Programmable inputs to be active high (PNP) or low (NPN). Optically
isolated.
2 Analogue Inputs: Programmable and differential input.
5 Digital Outputs: programmable multi-function relays.
2 Analogue Outputs: Programmable outputs in voltage / current.
24Vdc External Power Supply
3 meters and 5 meters (optional)
VISUALIZATION (POWER
ELECTRONICS LOGO)
MONOCHROME GRAPHIC
DISPLAY
Keypad with 68 keys to control and configure the drive, start and stop / reset
Wi-Fi communication module (optional)
TOUCH AND COLOUR GRAPHIC
DISPLAY (Optional)
Optional Colour touch-screen display 4.3”
4Gbytes for recording historical files
Panel or USB cable connection
Wi-Fi remote connection, micro-USB connection to control card
Average current and 3-phase motor current
Average voltage and 3-phase motor voltage
Average input voltage and 3-phase input voltage
3-phase motor input and output frequency
Speed, Torque, Power, Power Factor of the motor
Register of total and partial drive running time with reset function (hours)
Register of total and partial drive energy consumption with reset function (kWh)
Digital inputs / PTC status
Analogue inputs and sensor values
Motor and equipment overload status
IGBT and rectifier temperature
Fault history (last 6 faults)
