SD750
POWER ELECTRONICS
48
POWER CONNECTION
380-500Vac
FRAME
CODE
FUSES PER PHASE
(In)
5
SD750320 5B06DEF
1x350A
SD750400 5B06DEF
1x450A
6
SD750450 5B06DEF
2x350A
SD750570 5B06DEF
2x350A
SD750700 5B06DEF
2x450A
7
SD750800 5B06DEF
3x350A
SD750900 5B06DEF
3x350A
SD751050 5B06DEF
3x450A
8
SD751040 5B06DEF
4x350A
SD751400 5B06DEF
4x450A
9
SD751550 5B06DEF
6x350A
SD751800 5B06DEF
6x350A
SD751950 5B06DEF
6x450A
10
SD752250 5B06DEF
9x350A
SD752750 5B06DEF
9x450A
11
SD753100 5B06DEF
12x350A
Recommended protections for drives Frame 1 to Frame 4 are shown up next; they do not integrate
fuses. However, it should be noticed that the equipment installer must calculate the appropriate
protection for the application considering that the fuse complies with the following requirements:
Ultra-fast operation
Class aR according to VDE 636-23 and IEC 60269-4.
Recommended for drive protection use.
400-500 Vac. 6 PULSOS
FRAME
CODE
FUSE
CALIBER In
1
SD750006 5B06DEF
16
SD750008 5B06DEF
16
SD750011 5B06DEF
16
SD750015 5B06DEF
20
SD750024 5B06DEF
25
SD750030 5B06DEF
40
SD750040 5B06DEF
50
2
SD750048 5B06DEF
63
SD750060 5B06DEF
80
SD750075 5B06DEF
100
3
SD750095 5B06DEF
125
SD750110 5B06DEF
160
SD750145 5B06DEF
200
SD750180 5B06DEF
250
4
SD750200 5B06DEF
250
SD750260 5B06DEF
315
