Duecanali User Guide
FIGURE 3: Duecanali with DSP + AESOP rear panel view
Mains plug
Air vents
Ethernet +
AESOP ports
AES/EBU
main input
AES/EBU
aux input
Channel 2
line input
Channel 2
aux input
Channel 2
output
Channel 1
output
Channel 1
line input
alarm
outputs
channel 1
aux input
remote aux
command
(for aux input selection)
External aux power supply
A B CD E FG H I
A - V meter for channel 1 B - SmartCard reader C - Function button number 1 D - Function button number 2
E - Function button number 3 F - Function button number 4 G - Graphic LCD display H - V meter for channel 2
I - On/Off switch
Duecanali 5204
FIGURE 4: Duecanali detailed front panel view
