Precision Filters, Inc. 28000 Signal Conditioning System Installation Instructions
Rev. B
28000 System Installation
Page 53
Table 10 50-Pin Output Connectors: 28004-M3/M5, 28008-M3/M5, & 28016-M3 Mainframes
Conn System Address
FRAME n, ...
Pin Assignments
HI LO SHLD
J300* SLOT J0, CHAN 0 4 21 37
SLOT J0, CHAN 1 3 20 36
SLOT J0, CHAN 2 2 19 35
SLOT J0, CHAN 3 1 18 34
SLOT J1, CHAN 0 8 25 41
SLOT J1, CHAN 1 7 24 40
SLOT J1, CHAN 2 6 23 39
SLOT J1, CHAN 3 5 22 38
SLOT J2, CHAN 0 12 29 45
SLOT J2, CHAN 1 11 28 44
SLOT J2, CHAN 2 10 27 43
SLOT J2, CHAN 3 9 26 42
SLOT J3, CHAN 0 16 33 49
SLOT J3, CHAN 1 15 32 48
SLOT J3, CHAN 2 14 31 47
SLOT J3, CHAN 3 13 30 46
J301 SLOT J4, CHAN 0 4 21 37
SLOT J4, CHAN 1 3 20 36
SLOT J4, CHAN 2 2 19 35
SLOT J4, CHAN 3 1 18 34
SLOT J5, CHAN 0 8 25 41
SLOT J5, CHAN 1 7 24 40
SLOT J5, CHAN 2 6 23 39
SLOT J5, CHAN 3 5 22 38
SLOT J6, CHAN 0 12 29 45
SLOT J6, CHAN 1 11 28 44
SLOT J6, CHAN 2 10 27 43
SLOT J6, CHAN 3 9 26 42
SLOT J7, CHAN 0 16 33 49
SLOT J7, CHAN 1 15 32 48
SLOT J7, CHAN 2 14 31 47
SLOT J7, CHAN 3 13 30 46
*28004-M3/M5 uses only connector J300.
