PRECISION FILTERS Precision 28000 - Replacement Procedures; Replacing Fuses and Line Voltage Selection

Precision Filters, Inc. 28000 Signal Conditioning System Installation Instructions
Rev. B
Maintenance and Troubleshooting
Page 73
3.2 Replacement Procedures
This section describes the following procedures for replacing system components:
• Replacing fuses and changing the line voltage selection
• Replacing the backplane interface (BIF) card
• Replacing conditioning cards
• Replacing power supplies
WARNING
Unplug the 28000 system from the wall outlet and remove the power
cord before installing 28000 circuit cards or subsystem components or
performing any maintenance or replacement procedures.
3.2.1 Replacing Fuses and Line Voltage Selection
WARNING
For continued protection against re, replace the line fuse(s) only with the
fuse(s) specied for the power supply model number and the line voltage
selection being serviced.
Table 20 lists the appropriate power supplies for each mainframe.
Table 20 Cross-Reference of Mainframes and Power Supplies
Mainframe Model Number Power Supply Model Number
28002 PF-1UA-FA-120W
28004-M3/M5 28004-ACPS-1
28004-ACPS-2
28008-M3/M5 28008?-ACPS-1
28008?-ACPS-2
28008?-ACPS-3
28008?-ACPS-4
28016-M3
28016-M5
28016?-ACPS-1
28016?-ACPS-2
This section describes how to replace the fuse(s) for each of the 28000 system power supplies.
Each power supply has its own section listing the fuse(s) requirements and the procedure for
changing fuses.
