Precision Filters, Inc. 28000 Signal Conditioning System Installation Instructions
Rev. B
28000 System Installation
Page 55
Table 12 26-Pin Output Connector Pin Assignments for 4-Channel Cards
Channel Description Pin
CH0 Low 17
CH0 High 8
CH0 Shield Ground 26
CH1 Low 16
CH1 High 7
CH1 Shield Ground 25
CH2 Low 15
CH2 High 6
CH2 Shield Ground 24
CH3 Low 14
CH3 High 5
CH3 Shield Ground 23
Chassis Ground 9, 18
