EFX 885, 835, 825
Service Manual 20039-166
Page 19
©2011 Precor Incorporated, Unauthorized Reproduction and Distribution Prohibited by Law
4. If the Status shows Connected and the IP Address is not present, it will be necessary to either have the P80
software assist in acquiring the IP Address (Recommended) or enter the IP address manually. Touch
Configuration from the Connectivity menu.
5. Touch on the radio button next to Automatic, and then touch SETTINGS. See Diagram 3.7.3.
Diagram 3.7.3
6. The P80 will attempt to connect to the network, and when successful will acquire the networking information
screen and display the current network information. Once a good IP Address has been acquired, the P80 can
now be registered. Continue with step 12.
7. Note: Manually setting up the network configuration is not recommended. Precede with the following
procedure only with assistance from the facilities IT staff. Touch Configuration form the Connectivity menu.
8. Touch on radio button next to Manual, and then touch SETTINGS. See Diagram 3.7.4.
Diagram 3.7.4
9. Touch one of the network settings items from the Connectivity menu.
10. Enter the data acquired from the network administrator using the on-screen key pad, and then select OK. See
Diagram 3.7.5.
11. Repeat steps 9 and 10 for the remaining network settings.
