S3.25 Assembly and Maintenance Guide
page 26
1 2 3 4 5 6
13. Attach Lat Bar Holders
A. Attach the Lat Bar Holders to the Top Beam using
two 3¼-inch bolts
four washers
two locknuts
B. Wrench tighten.
Step 13. Attach Lat Bar Holders
2 - 3¼" bolts
4 - washers
2 - locknuts
A
Top Beam
