12.
Reinstall the frame cross member using the two front and two rear bolts, and wash-
ers using a 6 mm hex key.
13.
Thread the left/right chain tension adjustment nuts onto the adjustment bolt but do
not tighten. Pull the flywheel forward until the chain tension stops movement. Then align
the flywheel angle so that the front of the flywheel rim is equally spaced and centered
within the frame forks. Then tighten the tensioner nuts until snug.
14. Adjust the chain tension to specification, go to "Chain Drive Tension Adjustment" on
page12
15.
Tighten the left and right axle nuts , torque to 29.5 ft-lbs (40 Nm).
16.
Reinstall the rear chain sprocket finger guard , secure with two fasteners using a 5
mm hex key.
17. Replace front and rear chain guard covers in reverse order, see "Belt/Chain Guard
Cover Replacement" on page19.
18. Verify that the brake pad is centered on the flywheel and operating correctly.
19. Verify the bike operation per "Operation Verification Checklist" on page8 and return to
service.
.See Also
"Replacement Procedures" on page17
Contact Precor Customer Support at support@precor.com or 800.786.8404 with
any questions.
Page 30
5 Replacement Procedures
Chain Drive and Flywheel Replacement
