17 Accessories

The PRIMEDIC™ DefiMonitor XD is supplied with the following accessories fitted at the

factory:

• Paddle set

• PRIMEDIC™ SavePads Connect

• Power module: PRIMEDIC™ AkuPak

For details of further accessories, see separate list of accessories / price list.
