Primedic DefiMonitor XD - List of Error Codes

List of error codes
METRAX GmbH
DefiMonitor XD 21324 / GB / K05
81 / 116
14 List of error codes
The following table lists all messages that the unit emits when it switches off because of a
severe error. This switch-off is carried out with the spoken message "Internal Error"; the cause
of the error is displayed with the error code number from the first column and the text from the
second column. The other columns list the possible causes of the error and the remedial
measures that can be carried out by the user themselves
Error
code
Error text
Cause(s)
User action
50
HV, Internal FSM error
Error during the shock appliance
- return the device for servicing
51
HV, CPLD error
Error during the shock appliance
- return the device for servicing
52
HV, +5V voltage failed
Error in the voltage supply,
possibly due to an empty
accumulator/battery
- charge and/or replace the
power module
- if the error persists: Return the
device for servicing
53
HV, +5VSW voltage failed
Error in the voltage supply,
possibly due to an empty
accumulator/battery
- charge and/or replace the
power module
- if the error persists: Return the
device for servicing
54
HV, +24V voltage failed
Error in the voltage supply,
possibly due to an empty
accumulator/battery
- charge and/or replace the
power module
- if the error persists: Return the
device for servicing
55
HV, VREF voltage failed
Error in voltage reference
- return the device for servicing
56
HV, HVPWR voltage
failed
Error in the voltage supply,
possibly due to an empty
accumulator/battery
- charge and/or replace the
power module
- if the error persists: Return the
device for servicing
57
HV, RLPWR voltage failed
Error in the voltage supply,
possibly due to an empty
accumulator/battery
- charge and/or replace the
power module
- if the error persists: Return the
device for servicing
58
HV, Current setup DAC
failed
Error when setting the current
specifications - Failure in the
high voltage section
- return the device for servicing
59
HV, RTCCLK error was
detected
Error in generation of system
cycle
- restart the device
- if the error persists: Return the
device for servicing
60
HV, MCLK error was
detected
Dropout in system cycle
- restart the device
- if the error persists: Return the
device for servicing
61
HV, HVHALT event was
detected
Emergency shutdown during the
shock application
- return the device for servicing
62
HV, HVHALT net error
was detected
Error during the test of the
emergency shutdown
- return the device for servicing
63
HV, Disarm cannot be
performed
Error during the internal
discharge, impossible to
- return the device for servicing
