Primedic DefiMonitor XD - 19 Depiction of the Current Time Function

Depiction of the current time function
94 / 116
DefiMonitor XD 21324 / GB / K05
METRAX GmbH
19 Depiction of the current time function
The following diagrams show the graphs for the defibrillation pulse in manual mode, depending
on the load resistance.
Time / ms
Time / ms
Time / ms
I / A
5 Joule @ 25 Ohm
5 Joule @ 50 Ohm
5 Joule @ 75 Ohm
I / A
5 Joule @ 100 Ohm
5 Joule @ 125 Ohm
5 Joule @ 150 Ohm
I / A
5 Joule @ 175 Ohm
10 Joule @ 25 Ohm
10 Joule @ 50 Ohm
I / A
10 Joule @ 75 Ohm
10 Joule @ 100 Ohm
10 Joule @ 125 Ohm
