Depiction of the current time function
METRAX GmbH
DefiMonitor XD 21324 / GB / K05
95 / 116
I / A
10 Joule @ 150 Ohm
10 Joule @ 175 Ohm
20 Joule @ 25 Ohm
I / A
20 Joule @ 50 Ohm
20 Joule @ 75 Ohm
20 Joule @ 100 Ohm
I / A
20 Joule @ 125 Ohm
20 Joule @ 150 Ohm
20 Joule @ 175 Ohm
I / A
30 Joule @ 25 Ohm
30 Joule @ 50 Ohm
30 Joule @ 75 Ohm
I / A
30 Joule @ 100Ohm
30 Joule @ 125 Ohm
30 Joule @ 150 Ohm
