Primera LX500 User Manual

Label and Roll Specifications 41
Section 6: Label and Roll
Specifications
Important! Test all custom made label stock with the intended printer before
ordering large quantities! Primera will only assume responsibility for
custom label stock ordered from Primera.
Label Width
Liner Width
Distance from
edge of Media
to edge of Label
Width of Opening
Black Mark
Width
Gap Between
Labels
Label Height
Distance from
edge of Media
Label Sensing Methods
Method 1: Label
Gap Sensing
Method 2: Width of
thru-hole opening
Sensing
Method 3: Reective/Black
Mark Sensing
(Black Mark must be printed
on back side of label stock)
Note: See table below for Max and Min values in inches and mm..

Primera LX500 Specifications

General

Print Method	Inkjet
Max Print Width	4.25 inches
Interface	USB 2.0
Max Print Length	24 inches
Print Speed	Up to 2.5 inches per second
Ink Cartridge	Single CMY
Operating System Compatibility	Windows, Mac
Media Width	4.25 inches
Media Sensing	continuous
