Primera LX500 User Manual

30 Printing Using a PC
D. PRINTER DRIVER SETTINGS (PC)
Settings changed via the method below will apply to all new
designs created in BarTender or other programs after the pref-
erences were changed. Existing labels saved in BarTender will
not be affected since the preferences are saved with the label.
To change these preferences you will have to change printer
preferences through BarTender before printing by clicking the
"Document Properties" button.
To find Driver Settings:
Click the Start button, choose Printers and Faxes. Right-click
on the Color Label 500 Icon and select Printing Preferences
from the drop-down menu.
The preferences screen will appear.

Primera LX500 Specifications

General

Print Method	Inkjet
Max Print Width	4.25 inches
Interface	USB 2.0
Max Print Length	24 inches
Print Speed	Up to 2.5 inches per second
Ink Cartridge	Single CMY
Operating System Compatibility	Windows, Mac
Media Width	4.25 inches
Media Sensing	continuous
