Prins VSI LPG - Electrical Connections VSI-I Wiring Harness

Copyright © Prins Autogassystemen B.V. 2013 Page 25
Electrical connections VSI-I wiring harness
Check and measure the wiring in case of changes in the cars wiring colors.
13 IGNITION +
grey-white
Make a connection to ignition + / contact +.
Make sure that the voltage will not fail during starting the engine.
46 LAMBDA 1-L
orange
For the measurement of the lambda signal of cylinder bank 1.
Connect the wire parallel to the lambda sensor signal wire.
45 LAMBDA 2-R
orange-white
For the measurement of the lambda signal of cylinder bank 2.
Connect the wire parallel to the lambda sensor signal wire.
40 RPM
purple-white
For measuring the engine speed.
Connect to a Hall-sensor or camshaft sensor,
Make sure that the squared signal is not higher then 30 Volt !
Never connect to the ignition coil (only with a RPM module) !
Injector measure wire
( injection module )
39
38
37
36
11
10
9
8
Bicolour /
Full colour
For measuring / interrupting the petrol injectors :
Interrupt each petrol injector control wire ( injector min )
Each VSI wire has a cylinder number printed on the wire, connect
this wire to the corresponding petrol injector.
Connect the bicoloured VSI measuring wire to the ecu side,
( wire code: ECU SIDE ).
Connect the accompanying full coloured VSI wire to the
petrol injector side ( wire code: MIN INJ SIDE ).
See diagrams in Installation Manual General part 1 / 2.
Attention:
Each bicoloured measuring wire corresponds to a specific
LPG injector and cylinder number. Do not interchange the
wires.
Injection module => VSI-ecm => VSI injector rail
White-yellow vsi nr. 39 ( petrol injector cyl.1 ) =>VSI-ecm=> White-yellow vsi nr.33 ( vsi injector cyl.1 )
Green-yellow vsi nr. 38 ( petrol injector cyl.2 ) =>VSI-ecm=> Green-yellow vsi nr.32 ( vsi injector cyl.2 )
Pink-yellow vsi nr. 37 ( petrol injector cyl.3 ) =>VSI-ecm=> Pink-yellow vsi nr.31 ( vsi injector cyl.3 )
Blue-yellow vsi nr. 36 ( petrol injector cyl.4 ) =>VSI-ecm=> Blue-yellow vsi nr.30 ( vsi injector cyl.4 )
Grey-yellow vsi nr. 11 ( petrol injector cyl.5 ) =>VSI-ecm=> Grey-yellow vsi nr.05 ( vsi injector cyl.5 )
Bruin-yellow vsi nr. 10 ( petrol injector cyl.6 ) =>VSI-ecm=> Brown-yellow vsi nr.04 ( vsi injector cyl.6 )
Light blue-yellow vsi nr. 09 ( petrol injector cyl.7 ) =>VSI-ecm=> Light blue-yellow vsi nr.03 ( vsi injector cyl.7 )
Red-yellow vsi nr. 08 ( petrol injector cyl.8 ) =>VSI-ecm=> Red-yellow vsi nr.02 ( vsi injector cyl.8 )
