Prins VSI LPG - Diagram 14 Injection Module 4-Cylinder ( 180; 70024 Solder )

47
Diagram 14 Injection module 4-cylinder ( 180/ 70024 solder )
---
+
1 2
3
-
4
white min inj side 1
white-yellow 39 ecu side 1
petrol ecu
+
36 ecu side 4
39 ecu side 1
38 ecu side 2
26 SIMU LOW=ON
50 MAIN GROUND
petrol ecu
petrol ecu
petrol ecu
PETROL INJECTORS
4-CYLINDER SOLDER INJECTION MODULE VSI 1 REV.B 06-06-2005
green min inj side 2
green-yellow 38 ecu side 2
pink min inj side 3
pink-yellow 37 ecu side 3
blue min inj side 4
blue-yellow 36 ecu side 4
37 ecu side 3
VSI-4 computer
injection module
4 cylinder
180/70024
