Diagram 19 Repair module 180/30024 (4-8 cylinder)
injection
module
4 & 8 CYLINDER REPAIR INJECTION MODULE VSI 1 REV.B 180/30024 06-06-2005
INJ SIDE A
ECU SIDE A
INJ SIDE B
ECU SIDE B
INJ SIDE C
ECU SIDE C
INJ SIDE D
ECU SIDE D
ECU SIDE A
ECU SIDE D
ECU SIDE C
ECU SIDE B
50 MAIN GROUND
26 SIMU LOW=ON
4 cylinder
8 cylinder module A
8 cylinder module B
1 2 3 4
1 3
5 7
2 4 6 8
A B
C
D
REPAIR
MODULE
wire
