Chapter 4 INTERFACES Menu
Serial
Port
See page 119
Parallel
Port
1, 4
Port Type
IEEE 1284*
Disable
Centronics
Buffer Size in K
16*
1-16
Auto Trickle
Disable*
Enable
Trickle Time
1/4 sec*
1/2 sec
1 sec
2 sec
4 sec
8 sec
16 sec
Off
Timeout
10 sec.*
1 - 60 sec.
Report Status
Disable*
Enable
Prime Signal
Disable*
Enable
Offline Process
Disable*
Enable
USB
Port
Buffer Size in K
16*
1 - 16
Timeout
1
10 sec.*
1 - 60 sec.
Printer Mgmt
See page 120
INTERFACES
(con’d from
page 117)
Centronics
2
Data Bit 8
2
Enable*
Disable
PI Ignored
2
Enable*
Disable
Data Polarity
2
Standard*
Inverted
Resp. Polarity
2
Standard*
Inverted
Busy on Strobe
2
Enable*
Disable
Latch Data On
2
Leading*
Trailing
Prime Signal
Disable*
Enable
TOF Action
Reset*
Do Nothing
Buffer Size in K
16*
1-16
IEEE 1284
3
Prime Signal
Disable*
Enable
TOF Action
Reset*
Do Nothing
Buffer Size in K
16*
1-16
Offline Process
Disable*
Enable
Notes:
* = Factory Default
Italicized items are available only when Admin User is set to Enable (in the
PRINTER SETUP menu).
1
This menu appears only if Host Interface is set to Auto Switching (in the
Interfaces menu).
2
This menu appears only if Host Interface is set to Centronics (in the
Interfaces menu).
3
This menu appears only if Host Interface is set to IEEE 1284 (in the
Interfaces menu).
4
This menu does not appear when Centronics is selected (in the
Interfaces menu).
