Printronix SL5000 - Main Menu

95
Main Menu
Load Config.
Save Config.
Print Config.
Delete Config.
Power-Up Config.
Protect Configs.
Name Config 1
Name Config 2
Name Config 3
Name Config 4
Name Config 5
Name Config 6
Name Config 7
Name Config 8
Reset Cfg Names
Auto Save
CONFIG.
CONTROL
(page 115)
NOTES:
Italicized items are available only when you enable Admin User
(under PRINTER CONTROL).
1
Gap/Mark Sensor and Paper Out Sensor work in conjunction, as
shown in Table 6 on page 138. If you change the Gap/Mark Sensor
or Paper Out Sensor, you must recalibrate the media.
2
This menu appears only if an RFID encoder is installed.
3
This menu appears only if a Validator is installed.
4
This menu will not appear on Direct Thermal only printers.
5
This menu appears only if RFID is installed and there is no CST
bundle in the Flash File System.
6
This menu appears only if RFID is not installed and there is a CST
bundle in the Flash File System.
7
xxx represents the emulation name selected in the Active IGP Emul
menu.
VALIDATOR
3
Press to select the next main menu.
Press ↓ or ↑ to move within each main menu.
Press + or
− to cycle through each possible option or value.
.
.
.
Print Intensity
Print Speed
Print Mode
4
Media Handling
Paper Feed Shift
Label Length
Label Width
Ver Image Shift
Hor Image Shift
Orientation
Gap/Mark Sensor
1
Auto Calibrate
Validator Funct.
3
Active IGP Emul
xxx Diagnostics
7
Save Config.
Power-Up Config.
SMT: Status
5
PAA: Select Tool
6
QUICK
SETUP
(page 106)
Refer to the RFID
Labeling Reference
Manual
.
RFID
CONTROL
2
Refer to the Online
Data Validator
User’s Manual
