OPERATION
FIRST USE GUIDE
If this is you first operation, please follow the instructions carefully as below
before testing.
1. Please read user manual carefully and refer to page30:「Operating
process chart」 for learning operation instruction.
2. Please refer to page30: 「Operating process chart A. (Lang：)」 and
follow the procedures to select language: (Chinese/English).
3. Please refer to page30:「Operating process chart I.(Auto off time)」，
follow the procedures to select 15/30/60/120 min for auto power off time
setting.
4. Please refer to page30:「Operating process chart F.(Unit：)」，follow the
procedures to select unit：Meter / Feet /Yard.
5. If would like to change the setting, please follow the above instruction to
reset.
CABLE MAPPING
Caution!
• When performing cable mapping, select standard 1 to 1 or optional 1 to
8 remotes; both of receiver and remote unit cannot be used at the same
time, otherwise, the LCD will show incorrect test result. Single conductor
cable cannot be used for cable mapping.
• When performing cable mapping, do not connect the tested cable to any
electric circuit、equipment or adapter, it will affect the test result.
• Measuring cable length: the length of Lan cable must be longer than 1m
(3 Ft / 1 Yard), and the others must be longer than 1.25m (4 Ft / 1.35
Yard)。Maximum measuring distance is 610m (2,000Ft / 666 Yards).
• If short, open and crossover status occur at same time, “short” will show
up in first priority, please make the wire troubleshooting step by step.
