parts are inside.
• Turn off the Transmitter or Receiver and disconnect all test leads before
replacing the battery.
• Use only a 9V battery, properly installed in the case, to operate the
Transmitter and Receiver.
• If this equipment is used in a manner not specified by the manufacturer,
the protection provided by the equipment may be impaired.
INSTRUCTION
MT-7071 Transmitter/Remote Unit：
1. RJ45 (8 pin) connectors: Used for cable mapping and verifying cable
status of RJ45 (8 pin) LAN cable with remote unit; with tone generator
for wire tracing; for measuring cable length to open without remote unit.
Caution! Do not plug in live wire that over 5mA, 48V DC to RJ45 (8
pin) jack.
2. RJ11(6 pin) Connectors：Used for cable mapping and verifying cable
status of RJ11 (6P/6C/4C/2C) phone cable with remote unit; with tone
generator for wire tracing; for measuring cable length to open without
remote unit. Use alligator clip patch cord for cable mapping, cable length
measuring and verifying cable status of single conductor cable or two
conductor cable.
Caution! Do not plug in live wire having over 5mA, 48V DC to RJ11
(6 pin) jack.
3. BNC Connectors：Used for cable mapping and verifying cable status of
BNC Coax cable with remote unite; with tone generator for wire tracing;
for measuring cable length to open without remote unit. Use adaptor for
testing RF cable (such as F、RCA、TNC、M connectors).
Caution! Do not plug in live wire having over 5mA, 48V DC to BNC
(2pin) connector.
4. LCD Display：For indicating function and display test result.
