Calibration parameters Recall
Please refer to page30「Operating process chart H.( Load Data)」to select
「Calibration 1~ Calibration 7」then load the data for testing.
Measure Cable length
1. Make sure the measuring cable is in open circuit.
2. Measure length after recall calibration parameters, follow steps as
below.
Caution!
• Since there are many different cable specifications, brands and
manufacturers in the market, for ensuring correct measurement, please
set the cable calibration parameter as reference in advance. Before
measuring cable length, please recall the calibration parameter you set
and then measure cable length.
3. Connect MT-7071 and standard cable as figure 6.
4. Select unit if you want to change, please refer to page30「Operating
process chart F.(Unit：)」.
5. Select correct cable type as instruction of 「Operating process chart
B.(Type：)」.Then start to measure length calibration function.
6. Select 「Calibration 1~ Calibration 7」, please refer to page30「Operating
process chart H.( Load Data)」, follow the step and apply data for
testing.
7. Measure length as page30 「Operating process chart D.( Cable
Length)」.
8. If all of measuring results are same distances between testing points to
open points, please refer the instruction as figure 7
Test results for when all conductors are same length to opens. For
example as below, all of measuring results are 168.5m.
