PACKAGING
The MT-7071 comes with the accessories listed below. If any accessory is
damaged or missing, contact the place of purchase immediately.
MT-7071 LCD Cable Length Tone and Probe Kit
• MT-7071 Transmitter.
• MT-7071 Receiver.
• MT-7071 Remote unit, max. support 8pcs (optional MT-7071U)
• RJ45 (8 pin) to RJ45 (8 pin) patch cords.
• RJ11 (6 pin) to RJ11 (6 pin) patch cords.
• RJ11 (6 pin) to alligator clips patch cord.
• Earbud.
• Storage bag & User’s manual.
SPECIFICATIONS
MT-7071 Transmitter specifications
Display
LCD 128×64 Dots (50×27.5mm), with white backlight
Compatible connectors
RJ45(8 pin)、RJ11/12(6 pin)、BNC connectors
Cable types tested
RJ45 Lan cable Cat 5、5e、6 (UTP/STP)、RJ11/12
Telephone cable Cat 3 (2/4/6 pin)、Coaxial cable & normal
solid/stranded wire by alligator clips patch cord
Cable test modes
580/1160 Hz two-note tones for location and isolating
cables, wire mapping for validate (detects wire continuity,
shorts, opens, miswire (crossover) and open length
tested.
Measurement technology
Cable capacitance method
Max. distance of open length
＞1,200 meter (4,000 feet/1,300 yard), approx
Min. distance of open length
2 meter (6.8 feet/ 2.2 yard)
Typical accuracy of open
length
2~10 meter (6.8~33 feet/2.2~11yard) for reference
10~610 meter (33-2000 feet/ 11-666 yard.): ±5.0%
610~1,200 meter (2000~4000feet/ 666~1300 yard.) for
reference
Calibration accuracy of open
length
10~610 meter (33~2,000 feet/11~666 yard),
RJ45 Lan cable Cat 5、5e ±3.0%,
RJ45 Lan cable Cat6、RJ11/12 Telephone cable Cat 3
(2/4/6 pin)、Coaxial cable ±5.0%,
standard cable:10~50meter(33~164 feet/11~55 yard)
Resolution of open length
0.1 meter/ feet/ yard
Measurement rate
1~3 sec./time
Unit of open length
meters/ feet/ yards, selectable option
Calibrating parameters
memory
1~7 sets, allowing rewrite by new calibrating parameters
Tone frequency
580/1160 Hz
Max. distance of
transmission
≧3 km
