Prodigit 3350F Series User Manual

10 PRODIGIT
Model 3350F 3351F 3352F 3353F 3354F 3356F
Power 1200W 1800W 1200W 1800W 1800W 600W
Current 0~120A 0~120A 0~240A 0~240A 0~360A 0~120A
Voltage 0~60V 0~60V 0~60V 0~60V 0~60V 0~60V
Min. Operating Voltage 0.6V @ 120A 0.4V @ 120A 0.7V @ 240A 0.7V @ 240A 0.7V @ 360A 0.6V @ 120A
Constant Current Mode
Range
*1
0~12A/120A 0~12A/120A 0~24A/240A 0~24A/240A 0~36A/360A 0~12A/120A
Resolution 0.2mA/2mA 0.2mA/2mA 0.4mA/4mA 0.4mA/4mA 0.6mA/6mA 0.2mA/2mA
Accuracy
± 0.1% OF (Setting + Range)
Constant Resistance Mode
Range
0.0083~0.5~30KΩ 0.0083~0.5~30KΩ 0.0041~0.25~15KΩ 0.0041~0.25~15KΩ 0.0027~0.167~10KΩ 0.0083~0.5~30KΩ
Resolution
0.0083mΩ /0.033mS 0.0083mΩ /0.033mS 0.0041mΩ /0.066mS 0.0041mΩ /0.066mS 0.0027mΩ /0.1mS 0.0083mΩ /0.033mS
Accuracy
± 0.2% OF (Setting + Range)
Constant Voltage Mode
Range 6V/60V
Resolution 0.1mV/1mV 0.1mV/1mV 0.1mV/1mV 0.1mV/1mV 0.1mV/1mV 0.1mV/1mV
Accuracy
± 0.05% OF (Setting +Range)
Constant Power Mode
Range 120W/1200W 180W/1800W 120W/1200W 180W/1800W 180W/1800W 60W/600W
Resolution 2mW/20mW 3mW/30mW 2mW/20mW 3mW/30mW 3mW/30mW 1mW/10mW
Accuracy
± 0.5% OF (Setting + Range)
Dynamic Mode -CC
Timing
Thigh & Tlow 0.050~9.999 / 99.99 / 999.9 / 9999mS
Resolution 0.001 / 0.01 / 0.1 / 1mS
Accuracy 1uS/10uS/100uS/1mS + 50ppm
Slew rate
8mA~500mA/uS
80mA~5000mA/uS
8mA~500mA/uS
80mA~5000mA/uS
0.016A~1A/uS
0.16A~10A/uS
0.016A~1A/uS
0.16A~10A/uS
0.024A~1.5A/uS
0.24A~15A/uS
8mA~500mA/uS
80mA~5000mA/uS
Resolution 2/20mA/uS 2/20mA/uS 0.004/0.04A/uS 0.004/0.04A/uS 0.006/0.06A/uS 2m/20mA/uS
Accuracy
(5% of setting) ± 10 uS
Min. Rise Time 24uS(typical)
Current
Range
*2
12A/120A 12A/120A 24A/240A 24A/240A 36A/360A 12A/120A
Resolution 0.2mA/2mA 0.2mA/2mA 0.4mA/4mA 0.4mA/4mA 0.6mA/6mA 0.2mA/2mA
Accuracy
± 0.1% OF (Setting + Range)
Measurement
Voltage Read Back
Range (5 Digital) 0~6V/60V 0~6V/60V 0~6V/60V 0~6V/60V 0~6V/60V 0~6V/60V
Resolution 0.1mV/1mV 0.1mV/1mV 0.1mV/1mV 0.1mV/1mV 0.1mV/1mV 0.1mV/1mV
Accuracy
± 0.025% OF (Reading + Range)
Current Read Back
Range (5 Digital) 0~12A/120A 0~12A/120A 0~24A/240A 0~24A/240A 0~36A/360A 0~12A/120A
Resolution 0.2mA/2mA 0.2mA/2mA 0.4mA/4mA 0.4mA/4mA 0.6mA/6mA 0.2mA/2mA
Accuracy
± 0.1% OF (Reading + Range)
Power Read Back
Range (5 Digital) 0~1200W 0~1800W 0~1200W 0~1800W 0~1800W 0~600W
Resolution 0.01W
Accuracy
± 0.125% OF (Reading + Range)
Program mode(Mainframe)
Sequence No. F1~9/16 Steps
T1/T2 (Dwell) 0.1S~9.9S/Repeat 9999
Load Setting(External
Programming) 0~10V for CC mode F.S.
GO/NG Check Voltage/Current/Power
Protections
Over Power 105% of Rated Power
Over Current 105% of Rated Current
Over Voltage 105% of Rated Voltage
Over Temp. Yes
Interface(Mainframe)
RS-232 Optional
GPIB Optional
USB Optional

Prodigit 3350F Series Specifications

General

Brand	Prodigit
Model	3350F Series
Category	Power Supply
Language	English
