52 PRODIGIT

IMonitor

Ref_V

Shunt R

MOSFET_Nch

Power Supply

12V

Load+

Load-

Drain

source

Gate

Fig 3-4 an equivalent circuit in terms of the current monitor

Connecting the I-monitor to an oscilloscope

When you connect this product to an oscilloscope, please ensure the correct polarities of the

Connecting probes as shown in Fig. 3-5.

Fig 3-5 (Correct) Connections to an oscilloscope
