Prodigit 3350F Series User Manual

3350F Series Operation Manual 65
3-6. Initial setting of 3350F series load module
When you receive the 3350F series electronic load, the load value initial setting after power
ON is listed in table 3-1 ~ table 3-6 respectively, this is the factory or initial setting.
Item Initial value Item Initial value
CC L+Preset 0.000 A V_Hi 60.000 V
CC H+Preset 0.000 A V_Lo 0.000 V
CR H+Preset 30000 Ω I_Hi 120.00 A
CR L+Preset 30000 Ω I_Lo 0.00 A
CV H+Preset 60.000 V W_Hi 1200.0 W
CV L+Preset 60.000 V
LIMIT
W_Lo 0.0 W
CP L+Preset 0.00W SENSE Auto
CP H+Preset 0.00W LD-ON 1.0 V
T HI 0.050 mS LD-OFF 0.500 V
T L0 0.050 mS
CONFIG
POLAR+LOAD
RISE 8.0mA/uS SHORT Disable
DYN
FALL 8.0mA/uS OPP Disable
OCP Disable
Table 3-1 3350F initialize
Item Initial value Item Initial value
CC L+Preset 0.000 A V_Hi 60.000 V
CC H+Preset 0.000 A V_Lo 0.000 V
CR H+Preset 30000 Ω I_Hi 120.00 A
CR L+Preset 30000 Ω I_Lo 0.00 A
CV H+Preset 60.000 V W_Hi 1800.0 W
CV L+Preset 60.000 V
LIMIT
W_Lo 0.0 W
CP L+Preset 0.00W SENSE Auto
CP H+Preset 0.00W LD-ON 1.0 V
T HI 0.050 mS LD-OFF 0.500 V
T L0 0.050 mS
CONFIG
POLAR+LOAD
RISE 8.0mA/uS SHORT Disable
DYN
FALL 8.0mA/uS OPP Disable
OCP Disable
Table 3-2 3351F initialize
