All external inputs also work while the PROFINET
®
is enabled. The
external inputs lead to the expected reactions, as in the case of a
controller without PROFINET
®
functionality (see controller oper‐
ating instructions). The controller sends corresponding information
via the PROFINET
®
to the master (PLC Programmable Logic Con‐
troller, PC etc.).
Even if the remote configuration is set to inactive, the master is
able to read-access the controller data defined in the GSDML file.
If the remote configuration is inactive or switched to inactive, then
the settings for the operating mode selected prior to "inactive"
status are reloaded in the controller.
If the controller is switched to another operating mode, it stops and
can only be restarted using the
[Stop/Start]
key.
1. To access the
‘Menu’
: press the
[Menu]
key
2. Use the arrow keys to select the menu item
‘Setup’
and con‐
firm with
[OK]
ð
The
‘Device setup’
menu appears.
3. Use the arrow keys to select the menu item
‘Bus
configuration’
and confirm with
[OK]
ð
The
‘Configuration’
menu appears.
4.
In the
‘Configuration’
menu, you can:
n
‘Remote configuration’
– Switch remote configuration on or off.
n DHCP
– Switch DHCP on or off.
n
‘IP address’
– You can set the IP address here at which the con‐
troller can be accessed.
n
‘Subnet’
– You can set the address of the subnet here.
n
‘Gateway’
– You can set the address of the gateway here.
n
‘DNS’
– You can set the address of the DNS here.
n
‘Station name’
– You can set the station name as an actual word e.g.
"daca" or "daisy", using lower case letters only.
Origin of the designations
The different names and/or addresses represent
user-specific information and are the responsibility
of the system operator.
Supplementary Instructions for PROFINET
®
5
