To pin VDE cable Contact Relay
1 yellow "+" Current
output
4 Green “-" Current
output
3 white N/C (normally closed)
or
N/O (normally open)
Relay
2 brown C (common) Relay
Identity code c
2
3
1
4
P_G_0073_SW
Fig. 29: Assignment on the pump
Installation, electrical
48
