Reference MVI56E-GSC/GSCXT ♦ CompactLogix or MicroLogix Platform
User Manual Enhanced Generic ASCII Serial Communication Module
Page 98 of 140 ProSoft Technology, Inc.
April 24, 2017
GSCPORTCONFIGPARA
This low-level data type creates the tags and tag arrays required to organize and
hold configuration values for an application serial port. The values entered into
these tags will control the setup and operation of the port. This low-level structure
is used to create the higher-level structure, GSCPORTCONFIG (page 97).
GSCPORTDATA
This low-level data type creates the tags and tag arrays required to organize hold
incoming and outgoing data string values for an application serial port. The
values in these tags will be the data received or data to be transmitted on the
port. This low-level structure is used to create the higher-level structure,
GSCDATA (page 95).
