Chapter 1 Introduction
Page: 1-4
Prox-1635LF USER
′
S MANUAL
z WATCHDOG :
I / O port 0443H to Enable watchdog.
I / O port 0441H to Disable watchdog.
Watchdog function is selectable for Reset or NMI function.
Time-out timing select 0 / 8 / 16 / 24 / 32 / 40 / 48 / 56 / 64 / 72 / 80 / 88 / 96 /
104 / 112 / 120 sec +/- 25%.
z IDE INTERFACE :
One enhanced IDE port, support Ultra DMA-33/66/100.
One channel, support up to four devices.
z FLOPPY DISK DRIVER INTERFACE :
Support up to two Floppy Disk Drives, 3.5" and 5.25" ( 1.2M / 1.44M /
2.88M).
z USB CONNECTOR :
Universal Serial Bus Connector, support up to four USB 2.0 ports.
z LAN ADAPTER :
Single port, VIA 6103 PHY Chip
10/100 Base-TX Ethernet, support Wake-on-LAN
z CF Card Connector :
Compact Flash connector on board with second IDE, support type II CF.
z SERIAL PORT :
Two high speed 16550 Compatible UARTs with Send / Receive 16 Byte
FIFOs;
COM1 is fixed as RS-232; COM2 selectable for RS-232/422/485.
MIDI Compatible
Programmable Baud Rate Generator
z PARALLEL PORT :
SPP, ECP, EPP Function.
Bi-directional parallel port.
z GREEN FUNCTION :
Software supported by BIOS setup.
Hardware supported by switch control.
To Next Page
