Chapter 1 Introduction
Prox-1635LF USER
′
S MANUAL
Page: 1-5
z HARDWARE MONITORING FUNCTION :
CPUFAN
CPU Temperature
Auto Detect Voltage
z IRDA :
One Infrared port
z LED INDICATOR :
Hard Disk access
Power Indicator
z DMA CONTROLLER :
82C37 x 2
z DMA CHANNELS :
7
z INTERRUPT CONTROLLERS :
82C59 x 2
z INTERRUPT LEVELS :
15
z OPERATING TEMPERATURE :
0 to 60°C.
z INPUT POWER REQUIREMENT :
DC Voltage: +5V, minimum +4.75V, maximum 5.25V.
DC Ampere: 15A.
DC Voltage: +12V, minimum +11.4V, maximum 12.6V.
DC Ampere: 500mA.
z BOARD DIMENSIONS :
185mm x 122mm
z BOARD NET WEIGHT :
0.28 Kilograms.
