5Technical data
10 of 54
5. Technical data
5.1. Lathe:
Length between centres: 400 mm
Height of centres: 85 mm
Maximum work piece diameter: 116 mm
Machine base: Cross-ribbed surface, high-quality cast iron with ground
prismatic guide
Spindle: Oversized main spindle, supported with 2 adjustable
taper roller bearings
Spindle receiver: MK3
Spindle drill hole: 20.5 mm
Spindle concentricity: 5/1000 mm
Chuck (series): Precise RÖHM-3 jaw chuck, centrically clamped, 100
mm diameter
Sleeve receiver: MK2, retractable sleeve with scale
Spindle speeds: Adjustable with switch (two-stage) and by shifting the
drive belt (three-stage)
Switch setting 1: 80 / 330 / 1400 rev/min
Switch setting 2: 160 / 660 / 2800 rev/min
Motor rating: 550 W
Motor type: Induction motor
Size (L x D x H): 900 x 400 x 300 mm
Weight (complete): approx. 45 kg
