5Technical data
11 of 54
5.2. Drives of the tool axes
Spindle drive Z axis
(Leading spindle, longitudinal drive,
support):
Recirculating ball screw with 4mm pitch, effective
diameter 12mm. Stepping motor 1.8A, holding torque
50Ncm
Traverse path: 300mm
Spindle drive X axis
(Transverse drive, support):
Recirculating ball screw with 2mm pitch, effective
diameter 8mm. Stepping motor 1.8 A, holding torque 50
Ncm
Traverse path: 70mm
Activation of stepping motors:
Through CNC control unit (included)
Power supply:
Mains unit, output 35V (included)
5.3. Software and stepping motor controllers
Power supply
230V +-5%
Power consumption
min 150W
Gate
Serial interface - Connection cable to PC included
Stepping motor controller
Current control, pulse width modulation
Current reduction during standstill, clocking independent
of PC, microstepping
