Explosion hazardous areas
• VIBTOOL with intrinsic safety (VIB 2.700 EX) may only
be used with rechargeable batteries with the following
approval:
ZELM 05 ATEX 0243 U
• Rechargeable batteries must not be charged in explosive
environments! Only VIB 2.720 (EU), VIB 2.721 (USA) or
VIB 2.722 (UK) charging units may be used.
• The battery should not be removed under any circum-
stances! To replace a defective battery, VIBTOOL must
be sent back to the manufacturer.
• The accessories listed in the ‘Sensors & Accessories’
product catalog (VIB 9.663-1DG) are not allowed in
areas that contain inflammable dust!
• The VIBTOOL case (VIB 2.729) is not allowed in
explosion hazardous areas.
• Interface specification:
Analog output circuit: if the intrinsic safety protection is
type EEx ib IIC, it is only suitable for connection to
devices intended for this
U
O
= 11.6V
I
O
= 15mA
P
O
= 180mW
C
i
= 70nF
C
O
= 1.5µF
L
i
= 300µH
L
O
= 60mH
Temperature sensor circuit: if the intrinsic safety protec-
tion is type EEx ib IIC, it is only suitable for connection
to devices intended for this
U
O
= 11.6V
I
O
= 15mA
P
O
= 180mW
C
O
= 1.5µF
L
O
= 60mH
Digital output circuit / charging socket: if the intrinsic
safety protection is type EEx ib IIC, it is only suitable for
connection to devices intended for this
U
O
= 8.4V / I
O
= 84mA
P
O
= 180mW / C
O
= 6.8µF
L
O
= 3mH
