Pulsar ACCOLADE 2 LRF User Manual

Microphone
Turning on/off Microphone.
This item allows you to enable (or disable) the microphone for recording sound during video
recording.
1.
Press and hold the Menu (3) to enter the main menu.
2.
Select the Microphone menu item with the UP (2)/ DOWN (5) buttons.
3.
To turn on the microphone, briefly press the Menu (3) button.
4.
To turn off the microphone, briefly press the Menu (3) button.
To see the button operation scheme click here.

Pulsar ACCOLADE 2 LRF Specifications

General

Objective Lens Diameter	50 mm
Detection Range	1800 m
Sensor Resolution	640x480 pixels
Display Type	AMOLED
Pixel Pitch	17 µm
Frame Rate	50 Hz
Laser Rangefinder Range	1000 m
Protection level	IPX7
Dimensions	164x130x64 mm
Waterproof	Yes
Fogproof	Yes
Weight	0.7 kg
Display Resolution	640x480 pixels
Operating Temperature	-25 … +50 °C
Battery Type	Li-Ion Battery Pack
