Pulsar ACCOLADE 2 LRF User Manual

PiP Function
PiP ("Picture in Picture") allows you to see a zoomed image simultaneously with the main
image in a dedicated window.
Enabling / disabling the PiP function is carried out in the main menu (see section PiP
Mode).
Change zoom ratio in the PiP window with a short press of the DOWN (5) button.
The zoomed image is displayed in a dedicated window, while the image in the rest of the
screen is displayed at base magnification (2.5x).
When PiP is turned on, you can operate the discrete and continuous digital zoom. The full
optical magnification will take place only in the dedicated window.
When PiP is turned off, the image is shown with the optical magnification set for the PiP
function.
To see the button operation scheme click here.

Pulsar ACCOLADE 2 LRF Specifications

General

Objective Lens Diameter	50 mm
Detection Range	1800 m
Sensor Resolution	640x480 pixels
Display Type	AMOLED
Pixel Pitch	17 µm
Frame Rate	50 Hz
Laser Rangefinder Range	1000 m
Protection level	IPX7
Dimensions	164x130x64 mm
Waterproof	Yes
Fogproof	Yes
Weight	0.7 kg
Display Resolution	640x480 pixels
Operating Temperature	-25 … +50 °C
Battery Type	Li-Ion Battery Pack
