Pulsar ACCOLADE 2 LRF User Manual

External Power Supply
The device can be powered with an external power supply such as Power Bank (5 V).
1.
Connect the external power supply to the USB port (15) of the device.
2.
The device switches to operation from external power supply, and the IPS7 Battery Pack
will begin slowly charging.
3.
The display will show the battery icon with charge level as a percentage.
4.
If the device operates on external power supply but the IPS7 battery is not connected,
icon is shown.
5.
When the external power supply is disconnected, the device switches to the internal
battery pack without powering off.
Warning! Charging IPS7 / IPS14 batteries at air temperatures below 0° C (32° F) may reduce
battery life. When using external power, connect the Power Bank to the device after it has
been turned on and working for several minutes.
To see the Components and Controls scheme click here.

Pulsar ACCOLADE 2 LRF Specifications

General

Objective Lens Diameter	50 mm
Detection Range	1800 m
Sensor Resolution	640x480 pixels
Display Type	AMOLED
Pixel Pitch	17 µm
Frame Rate	50 Hz
Laser Rangefinder Range	1000 m
Protection level	IPX7
Dimensions	164x130x64 mm
Waterproof	Yes
Fogproof	Yes
Weight	0.7 kg
Display Resolution	640x480 pixels
Operating Temperature	-25 … +50 °C
Battery Type	Li-Ion Battery Pack
