Pulsar ACCOLADE 2 LRF User Manual

Microbolometer Calibration
Calibration eliminates image flaws (such as vertical bars, phantom images, grainy field of
view, etc.) by equalizing the microbolometer background temperature.
There are three calibration modes: manual (M), semi-automatic (SA) and automatic (?).
Select the desired mode in the menu option Calibration Mode .
Mode ? (manual)
Close the lens cover.
Press briefly the ON/OFF (1) button.
Open the lens cover.
Mode SA (semi-automatic)
Press briefly the ON/OFF (1) button to calibrate.
You do not need to close the lens cover (the microbolometer is closed with the internal
shutter automatically).
Mode ? (automatic)
The device calibrates by itself according to the firmware algorithm.
You do not need to close the lens cover (the microbolometer is closed with the internal
shutter automatically).
In the automatic mode, the user can calibrate the microbolometer with the ON/OFF (1) (in
the SA mode) button.
To see the button operation scheme click here.

Pulsar ACCOLADE 2 LRF Specifications

General

Objective Lens Diameter	50 mm
Detection Range	1800 m
Sensor Resolution	640x480 pixels
Display Type	AMOLED
Pixel Pitch	17 µm
Frame Rate	50 Hz
Laser Rangefinder Range	1000 m
Protection level	IPX7
Dimensions	164x130x64 mm
Waterproof	Yes
Fogproof	Yes
Weight	0.7 kg
Display Resolution	640x480 pixels
Operating Temperature	-25 … +50 °C
Battery Type	Li-Ion Battery Pack
