Pulsar ACCOLADE 2 LRF User Manual

Calibration Mode
There are three calibration modes: manual (M), semi-automatic (SA) and automatic (?).
1.
Press and hold down the ?enu (3) button to enter the main menu.
2.
Select the Calibration Mode option.
3.
Press briefly the Menu (3) button to enter submenu.
4.
Select the desired calibration mode with the UP (2)/DOWN (5) buttons.
5.
Confirm your selection with a brief press of the Menu (3) button.
More details in the section Microbolometer Calibration.
To see the button operation scheme click here.

Pulsar ACCOLADE 2 LRF Specifications

General

Objective Lens Diameter	50 mm
Detection Range	1800 m
Sensor Resolution	640x480 pixels
Display Type	AMOLED
Pixel Pitch	17 µm
Frame Rate	50 Hz
Laser Rangefinder Range	1000 m
Protection level	IPX7
Dimensions	164x130x64 mm
Waterproof	Yes
Fogproof	Yes
Weight	0.7 kg
Display Resolution	640x480 pixels
Operating Temperature	-25 … +50 °C
Battery Type	Li-Ion Battery Pack
