Pulsar ACCOLADE 2 LRF User Manual

Device Information
This option allows the user to view the following information about the device:
Full name
SKU number
Serial number
Firmware version
Hardware version
Service information
To display information, do the following:
1.
Press and hold down the?enu (3) button to enter the main menu.
2.
Select option Device Information with the UP (2)/DOWN (5) buttons.
3.
Press briefly the ?enu (3) button to confirm.
To see the button operation scheme click here.

Pulsar ACCOLADE 2 LRF Specifications

General

Objective Lens Diameter	50 mm
Detection Range	1800 m
Sensor Resolution	640x480 pixels
Display Type	AMOLED
Pixel Pitch	17 µm
Frame Rate	50 Hz
Laser Rangefinder Range	1000 m
Protection level	IPX7
Dimensions	164x130x64 mm
Waterproof	Yes
Fogproof	Yes
Weight	0.7 kg
Display Resolution	640x480 pixels
Operating Temperature	-25 … +50 °C
Battery Type	Li-Ion Battery Pack
