Rangefinder
Menu item Rangefinder allows you to set up built-in rangefinder’s parameters as follows:
1.
Enter the main menu with a long press of the Menu (3) button.
2.
Select the submenu Rangefinder with the UP (2)/DOWN (5) buttons.
3.
Enter the submenu with a short press of the Menu (3) button.
4.
Select the desired menu item with the UP (2)/DOWN (5) buttons.
Reticle Type
1.
Select the Reticle Type menu item with the UP (2)/DOWN (5) buttons.
2.
Press briefly the ?enu (3) button to enter submenu.
3.
Select one of the three reticle shapes with the UP (2)/DOWN (5) buttons.
4.
Confirm selection with a brief press of the ?enu (3) button.
5.
Selected reticle will appear on the display.
6.
The reticle will disappear from the display if the rangefinder is not used longer than 4
seconds.
Target Position Angle (TPA)
Function "TPA" allows you to change the angle of target location (angle of elevation). When
the function is activated, the angle is shown continuously. When the function is disabled, the
angle is shown if the rangefinder is working. The angle is shown in a pop-up menu during
measurement.
1.
Select TPA with the UP (2)/DOWN (5) buttons.
2.
Turn TPA on/off with a short press of the ?enu (3) button
True Horizontal Distance (THD)
"THD" function allows you to measure true horizontal distance to a target based on the angle
of elevation value.
1.
Select THD with the UP (2)/DOWN (5) buttons.
2.
Turn THDon/off with a short press of the ?enu (3) button
3.
Hereinafter the message THD will appear above the distance readings.
To see the button operation scheme click here.
