2. Select the submenu General Settings with the UP (5)/DOWN (7) buttons.
3. A short press of the MENU (6) button opens the submenu.
4. Press UP (5)/DOWN (7) buttons to select Display Position
Calibration menu item.
5. A short press of the MENU (6) button opens the submenu.
6. Press briefly the MENU (6) button to open the submenu Calibration
Profile .
7. Select one of the calibration profiles (shown with letters A; B; C) with UP
(5)/DOWN (7) buttons.
8. Confirm your selection with a short press of MENU (6) button.
9. The name of the selected profile appears in the status bar.
Position Calibration
1. To freeze the image, select Freeze and briefly press the MENU
(6) button.
2. Press UP (5)/DOWN (7) buttons to select Position Calibration menu
item.
3. Confirm your selection with a short press of MENU (6) button. Display
coordinates X=0; Y=0 and click value will appear.
