Pulsar Zenith 140 - Relay Type Configuration

PULSAR MEASUREMENT
71
P210, 220, 230, 240, 250, 260 - Relay Type
This parameter defines what type each relay should be, see the table below
for available options:
OPTION
DESCRIPTION
0 = Not in use (Default)
Relay is not in use or programmed and the LED will
always be off.
1 = Alarm
Relay is programmed as an alarm relay, which will de-
energise ON, and energise OFF. This will ensure an
alarm is raised if the power fails to the unit.
2 = Pump
Relay is programmed as a pump relay, which will
energise ON, and de-energise OFF.
3 = Control
Relay is programmed as a control relay, which will
energise ON, and de-energise OFF.
4 = Miscellaneous
Relay is programmed as a miscellaneous relay, which will
energise ON, and de-energise OFF.
5 = Pump by time
Relay is programmed as a pump relay, which will
energise at its ON level setpoint, and de-energise at its
OFF level setpoint or after a predetermined time period,
whichever occurs first.
