ZENITH 140 INSTRUCTION MANUAL
64
Application Parameters
Operation
P100 Mode of Operation
This parameter sets the mode of operation, when in run mode, and can be
set to one of the following:
OPTION
DESCRIPTION
1 = Distance (Default)
Display shows the distance from the transducer face
to the surface of the material measured.
2 = Level
Shows how full a vessel is.
3 = Space
Shows how empty a vessel is.
4 = Average Level
Display shows the average level of two points of
measurement.
5 - Differential
Display shows the Differential level between 2 points
of measure.
P101 Xducer (Transducer)
This parameter should be set to the transducer being used with the unit, and
can be set to one of the following:
OPTION
DESCRIPTION
0 = Auxiliary
Use a mA input
1 = dB3
Transducer is a dB3. Range = 0 to 3 metres
2 = dB6 (default)
Transducer is a dB6. Range = 0.3 to 6 metres
3 = dB10
Transducer is a dB10. Range = 0.3 to 10 metres
4 = dB15
Transducer is a dB15. Range = 0.5 to 15 metres
5 = dB25
Transducer is a dB25. Range = 0.6 to 25 metres
6 = dB40
Transducer is a dB40. Range = 1.2 to 40 metres
7 = dBS6
Transducer is a dBS6. Range = 0.2 to 6 metres
8 = dBMach3
Transducer is a dBMach3. Range 0.3 to 2.425 metres
*11 = dBR16
Transducer is a mmWave radar. Range 0.077 to 16 metres
*12 = dBR8
Transducer is a mmWave radar. Range 0.077 to 8 metres
P102 Material
This parameter should be set to the type of material being monitored.
Important Notice
*Please consult your local Pulsar distributor for the versions of firmware that the
mmWAVE radars are available in.
