Pulsar Zenith 140 User Manual

PULSAR MEASUREMENT
29
Hot Keys
There are five hot keys on the keypad, which can be used to quickly access
common parameters for viewing only, while in Run Mode. Pressing the hot
key once will display the first parameter, then repeated pressing will display
the others, then the Zenith reverts to Run Mode. In program mode, they
have different functions, the functions are shown below.
HOT KEY
RUN MODE
PROGRAM MODE
Total pump running hours and
individual pump running hours.
Not used with Zenith 140
Displays echo confidence, echo
strength, height above loss limit (HALL),
average noise, peak noise, and
temperature
Not used with Zenith 140
Total number of pump starts, and
individual pump starts.
Reset parameter to default
setting
Instantaneous mA output
Not used with Zenith 140
Dependent on application. Displays
distance, level, space, volume or rate of
change of level.
Toggle relay setpoints
between units of measure and
% of span.
Reset for digital inputs
Takes you to the last
parameter edited when you
first enter program mode.
Shows details of function type, firmware
revision and serial number
Enter decimal point.
∑
mA
n
