0020 Exit Starts All At the start of the exit time to set the
LAST area.
At unset FIRST area (such as no
longer fully set).
0021 Exit Starts Any When the exit time starts to set the FIRST
area.
At code entry to unset LAST area.
0022 Final Set Any When ANY area has been set. At code entry to unset LAST area.
0023 Strobe Set Fail Works similar to output 016, but also fires if the ‘set fail’ timer expires.
0025 Keyswitch Unset This output turns on for five seconds when the system is disarmed via a
keyswitch input (pulsed or latched).
0026 Set with Omit Active when the system is set with an input omitted.
0028 Power Fault Active during low volts and battery faults. Restores at code entry after the fault
is cleared.
0029 Confirm Intruder
Any
When more than one intruder alarm
activates.
At next code entry.
0030 Confirm HU Any When more than one confirmed HU
activates.
At the next code entry.
0031 Entry Active during any entry time.
0032 Exit Active during any exit time.
0033 Entry / Exit Active during any entry or exit time.
0034 Lights When the exit or entry timer starts. 20 seconds after the set/unset
procedure has completed.
0035 Follow Input Active when a specific input number has been activated. It allows the following
options to be programmed:
-
Follow Type (Follow, Timed, Latched, Code Reset);
-
Follow What (Input, Shunt List, Sub-Area, Area);
-
Follow When (Always, When Armed, When Disarmed);
-
Input to Follow
0036 Shunt Fault After an input in the shunt list is opened with an active detector (attempting to
unshunt) the ‘Shunt Fault’ output pulses until the shunt is reset.
0037 Restore 1 At code entry to set. The normal state of
this input is 0v and it changes to 12v
when activated.
After three seconds.
0038 Restore 2 Activates whenever an additional area is
set. The normal state of this input is 0v
and it changes to 12v when activated.
When unset,
0039 PIR Latch 1 When set (and in Walk Test). At alarm, or when unset.
0040 PIR Latch 2 This is the inverse polarity to
PIR Latch 1.
At alarm, or when unset.
0041 Mains Good Output showing the 230v mains supply is present.
0042 Detr Indn Enable Output activates during walk test and also when a code is entered to view
detector indications (staying activated for the time that indications are viewed).
0043 Follow Test Output will activate only when tested from the Engineer menu ‘Test Outputs’ in
the ‘Engineer Tests’. This output can be used as an additional facility for testing
the operation of a Bell. An output programmed to one of these configurations (43
and 44) may be used to trigger a relay to break the hold-off connection to the
Bell – or even to provide the hold-off directly.
0044 Off During Test Output is normally active and will deactivate only when tested from the Engineer
menu ‘Test Outputs’ in the ‘Engineer Tests’ (the same as 43 but opposite
activation).
0048 Detr Walk Test This output is active during walk test and will only deactivate when all detectors
have been tested.
0049 Detector Masked If any detector goes into ‘mask’ condition
the output will activate.
When the masking fault clears.
0050 Follow 24 Hour If any input programmed as ‘24 Hour’
activates.
When the input is restored.
To Next Page
