Page: 9
5.4 Change Inputs?
By default, all inputs are set to ‘unused’. Before programming, identify the input type required:
#
These inputs cannot be bypassed.
*
Use of inputs 20 and 23 will make the system unable to comply with EN50131-1 Security Grade 2.
$
Ensure that these inputs are used on an entry/exit route
5.4.1 Choose Input
Choose an input to program.
Input Type: Assign an input type to the chosen input:
No Input Types Operation
00 Unused
Factory default. Input is disabled.
01 Fire Active at all times. Audible Response: Differentiated Internal sound. Pulsed
external sound. Communicator: ‘Fire’ signal
02 Gas Active at all times. Audible Response: Full external + Internal sound.
Communicator: ‘Gas’ signal
03
HU
#
Active at all times. Audible Response: Differentiated Internal sound. Full external
sound. Communicator: ‘Hold Up’ (PA) and ‘Input HU’ signals
04
Silent HU
#
Active at all times. Audible Response: None
Communicator: ‘Hold Up’ (PA) and ‘Input HU’ signals
05 Tamper When unset: Audible Response: Internal only. Communicator: ‘Tamper’ signal.
When set: Audible Response: Full external +Internal sound. Communicator:
‘Tamper’ signal.
06 Intruder Active when set: Audible Response: Full external + Internal sound.
Communicator: ‘Intruder’ and ‘Unconfirmed’ signals
07
Final Exit
(FX)
# $
Active when set: – initiates entry timer if system not unset before entry time
expires: Audible Response: Full.
Communicator: ‘Intruder’ and ‘Unconfirmed’ signals.
08
Entry Route
(ER)
$
Active when set, except during entry time.
Audible Response: Full.
Communicator: ‘Intruder’ and ‘Unconfirmed’ signals.
09
ER
(Area FX)
When fully set (A), acts as Entry route input, as above. When area set (B,C,D),
acts as Final Exit input, as above.
10
FX
(Area ER)
When fully set (A), acts as Final Exit input, as above. When area set (B,C,D), acts
as Entry route input, as above.
11 PTS
Active during exit time to complete Setting procedure
No audible or communicator response.
Note: May be used to act as ‘doorbell’ by use of ‘chime’ attribute.
12 Switcher
Active at all times: This Input Type is used when you want an input to be used to
trigger an output, but not an alarm. It will function whether the panel is set or
unset and can be used to illuminate a light, or trigger a CCTV camera etc. NOTE: If
the input has Masking or Tamper functions – then these will still trigger an alarm, it
is only regular activations that will not.
13 Day Alarm
When set: Internal (‘beep’) Response: Full; Communicator: ‘Instant’ signals.
When unset: Audible (sounder) Notification: Programmable; Communicator: ‘24hr
Alarm’ signal (if programmed in Alarm Responses menu).
15 Ward Control
Input is allocated by system software and cannot be reprogrammed to a different
type, though relevant attributes may be adjusted.
16 Fault
When set: Audible Response: Full; Communicator: ‘Instant’ signals.
When unset: Audible Response: Programmable; Communicator: ‘24hr Alarm’
signal (if programmed in Alarm Responses menu).
17
Closure
Supervision
Active during Setting procedure. No audible or communicator response.
Prevents system being set whilst active.
18 Shunt Input
Active at all times. No audible or communicator response. Accepts input from
keyswitch (or equivalent) to shunt the inputs assigned to it. Associated outputs are
available. After 10 seconds the detectors in the shunt list will be active.
19 Unset Input
Active when set. Accepts input from keyswitch (or equivalent) to
Unset the Area/Level set assigned to it.
20
Keyswitch
Latched
*
Accepts input from keyswitch (or equivalent) to Set/Unset the Set modes assigned
to it. Setting includes normal exit time, etc. Requires latching action switch.
21
Entry Shock
Input
Active when system set. Works in conjunction with EE input type for detection of
forced entry
.
To Next Page
