Page: 15
0051 Comms Fault When the Telephone / Network or GPRS
Line Fault is present.
When the fault clears.
0052 Mains Fail After the pre-set time without mains
power.
Upon restoration of mains.
0053 Battery Fault When the battery is disconnected or load
fail is detected.
At the next valid code entry.
0054 Low Volts When less than 11.2v are present. When the fault clears.
0055 Global Fault 1
(Grade 2)
Activates if any fault occurs (only when
the system is set).
When all faults are cleared.
0056 Global Fault 2
(Grade 3)
Activates if any fault occurs (at any time). When all faults are cleared.
0057 German Relay For future development. DO NOT USE.
0058 Guard Code Used When ‘guard’ code is used on the system After 60 seconds.
0059 Engineer Access When entering Engineer mode. When leaving Engineer mode.
0060 Initialise Digi At power up. Live for 45 seconds.
0063 Test ATE/GSM Activates when a test call is sent. When the test is completed.
0064 Test ATS
For use with ATE
complying with BSIA
Form 175 to initiate
test call to ARC by
each available path.
Test signalling through PSTN and GSM.
Activates when a test call is sent.
When the test is completed.
0065 Zone Activity Fault This is the output that will activate in response to the ‘Monitor Activity’ Input,
once the programmed NAT time has elapsed. It will be cleared / restored by the
next valid code entry.
0066 ATE Not Used Makes the ATE pin 5V or 0V depending on whether ATE outputs are inverted.
0170
--
0199
User Defined 01-30 The user outputs are used for user automation to control external devices. They
can be controlled via the keypad from the user menu and can be programmed as
‘latched’ or ‘timed’ (1 to 99 sec).
0202 Hold Up A (As 0002 for Area A ) 0213 Secure Int A (As 0013 for Area A )
0203 Intruder A (As 0003 for Area A ) 0214 Siren A (As 0014 for Area A)
0204 Final Set A (As 0004 for Area A ) 0216 Strobe A (As 0016 for Area A )
0206 Confirmed A (As 0006 for Area A) 0217 Omit At Reset/rearm A (As 0017 for Area A )
0207 Tamper A (As 0007 for Area A ) 0218 Unconfirmed A (As 0018 for Area A )
0208 Duress A (As 0008 for Area A ) 0219 Can Set A (As 0019 for Area A )
0209 HU Device A (As 0009 for Area A ) 0220 Exit Starts A (As 0020 for Area A )
0210 Fire Reset A (As 0010 for Area A )
Then this pattern repeats for all other areas other areas so that:
0222-0240 Area B 0242-0260 Area C 0262-0280 Area D 0282-0300 Area 0 0302-0320 Area 1
0600-0609 Timers 01-10: For future development 0610-0619 Calendar 01-20: For future development
0620-0639 UDL Programmable Logic Gates 1-20. 0640-0649 Delay 01-10: For future development
1001-1046 Active when input opened and close when input is closed
*The use of pulsed or latched keyswitch will make the system unable to comply with EN50131-1
